ASUS الشرق الاوسط تطلق مجموعة لوحاتها الرئيسية التي تعمل بشريحة B450
ROG Strix B450 MotherBoards :
TUF Gaming’s B450 MotherBoards:
وهنا جدول لتوضيح مواصفات ال4 لوحات السابقة :
| Model Name | ROG STRIX B450-F Gaming | ROG STRIX B450-I GAMING | TUF B450-PLUS GAMING | TUF B450M-PLUS GAMING | |
| CPU | AM4 socket for AMD Ryzen™ 2nd Generation/Ryzen™ 1st Generation /Ryzen™ with Radeon™ Vega Graphics Processors | ||||
| Chipset | AMD B450 Chipset | ||||
| Form Factor | ATX (12 x 9.6 in.) | ITX (6.7 x 6.7 in.) | ATX (12 x 9.6 in.) | mATX (9.6 x 9.6 in.) | |
| Memory | 4 / 64 GB DDR4 | 2 / 32GB DDR4 | 4 / 64 GB DDR4 | 4 / 64 GB DDR4 | |
| 3200 MHz (O.C.) | 3600 MHz (O.C.) | 3200 MHz (O.C.) | 3200 MHz (O.C.) | ||
| Graphics Output | HDMI 2.0b/ DP | HDMI 2.0b | HDMI 2.0b/DVI-D | HDMI 2.0b/DVI-D | |
| Expansion Slot | PCIe 3.0 x16 | 2 @ x16 or x8/x4 | 1 supports x16 | 1 @ x16 or x8 | 1 @ x16 or x8 |
| PCIe 2.0 x 16 | 1 max @ x4 | - | 1 max @ x4 | 1 max @ x4 | |
| PCIe 2.0 x1 | 3 | - | 3 | 1 | |
| SATA 6Gb/s | 6 | 4 | 6 | 6 | |
| M.2 | 1x 2280 (SATA + PCIe 3.0 x4) | 1x 2280 (SATA + PCIe 3.0 x4) | 1x 22110 (SATA + PCIe 3.0 x4) | 1x 22110 (SATA + PCIe 3.0 x4) | |
| 1x 22110 (PCIE 3.0 x4 mode) | 1x 2280 (PCIE 3.0 x4 mode) | N/A | N/A | ||
| USB 3.1 Gen 2 | 2 x Type-A | 2 x Type-A | 2 Type-A | 1x Type-A | |
| USB 3.1 Gen 1 | 1 x Type-C at back 3 x Type-A at back 2 x Type-A at front | 4 x Type-A at back 2 x Type-A at front | 1 x Type-C at back 2 x Type-A at back 2 x Type-A at front | 1x Type-C at back 2x Type-A at back 2x Type-A at front | |
| USB 2.0 | 6 | 2 | 6 | 6 | |
| Networking | Gigabit Ethernet | Intel® I211AT | Intel® I211AT | Realtek® 8111H | Realtek® 8111H |
| Wireless | N/A | 2x2 Wi-Fi with MU-MIMO 802.11 a/b/g/n/ac supports dual frequency band 2.4 / 5 GHz | N/A | N/A | |
| Audio | Codec | SupremeFX S1220A | SupremeFX S1220A | Realtek® ALC887 | Realtek® ALC887 |
| Effects | Sonic Radar III Sonic Studio III Sonic Studio Link | Sonic Radar III Sonic Studio III Sonic Studio Link | DTS Custom for GAMING Headsets | DTS Custom for GAMING Headsets | |
| Aura | Aura Sync | V | V | V | V |
| 4-pin RGB Header | 1 | 1 | 1 | 1 | |
| Addressable RGB header | N/A | 1 | N/A | N/A | |
| Others | Pre-mounted I/O Shield SafeSlot | M.2 Audio Combo Card SafeSlot | SafeSlot | SafeSlot | |
Prime B450 MotherBoards:
والفرق بين ال3 موديلات من اللوحات :
| Model Name | PRIME B450-PLUS | PRIME B450M-A | PRIME B450M-K | |
| CPU | AM4 socket for AMD Ryzen™ 2nd Generation/Ryzen™ 1st Generation /Ryzen™ with Radeon™ Vega Graphics Processors | |||
| Chipset | AMD B450 Chipset | |||
| Form Factor | ATX (12 x 9.6 in.) | mATX (9.6 x 9.5 in.) | mATX (8.9 x 8.7 in.) | |
| Memory | 4 / 64 GB DDR4 | 4 / 64 GB DDR4 | 2 / 32GB DDR4 | |
| 3200 MHz (O.C.) | 3200 MHz (O.C.) | 3200 MHz (O.C.) | ||
| Graphics Output | HDMI 2.0b / DVI-D | HDMI 2.0b / DVI-D / D_Sub | DVI-D / D_Sub | |
| Expansion Slot | PCIe 3.0 x16 | 1 @ x16 or x8 | 1 @ x16 or x8 | 1 @ x16 or x8 |
| PCIe 2.0 x 16 | 1 max @ x4 | - | - | |
| PCIe 2.0 x1 | 3 | 2 | 2 | |
| SATA 6Gb/s | 6 | 6 | 4 | |
| M.2 | 1x 22110 (SATA + PCIe 3.0 x4) | 1x 22110 (SATA + PCIe 3.0 x4) | 1x 2280 (SATA + PCIe 3.0 x4) | |
| N/A | N/A | N/A | ||
| USB 3.1 Gen 2 | 2 Type-A | 2 Type-A | 2 Type-A | |
| USB 3.1 Gen 1 | 1 x Type-C at back 2 x Type-A at back 2 x Type-A at front | 4 Type-A at back 2 Type-A at front | 4 x Type-A at back 2 x Type-A at front | |
| USB 2.0 | 6 | 4 | 4 | |
| Networking | Gigabit Ethernet | Realtek® 8111H | Realtek® 8111H | Realtek® 8111H |
| Wireless | N/A | N/A | N/A | |
| Audio | Codec | Realtek® ALC887 | Realtek® ALC887 | Realtek® ALC887 |
| Effects | N/A | N/A | N/A | |
| Aura | Aura Sync | V | V | N/A |
| 4-pin RGB Header | 1 | 1 | N/A | |
| Addressable RGB header | N/A | N/A | N/A | |
في النهاية دائما اعتادت اسوس على تقديم كافة الخيارات والمميزات لعشاقها سواء من اللاعبين او هواة كسر السرعة او صناع المحتوى والعمل الشاق بشكل عام والان خرجت لنا بمجموعة لوحات ASUS STRIX/TUF/PRIME B450 لتغطي جميع الاحتياجات لاي مستخدم كان ...
